LFG-1020-050, Fiber Optic Sensor 50 mm 25 mm Bending Radius
Product Attributes
Sensing Range: 2 mm Polarity: PNP Connection Type: 2 m 3 Wire Thread Size: M12 x 1 Connector Size: 12 mm Supply Voltage: 10 to 30 V dc Current Rating: ≤200 mA No-Load Supply Current: ≤10 mA Leakage Current: ≤0.1 mA Maximum Switching Frequency: ≤3000 Hz Oscillator Frequency: 360 kHz Temperature Drift: ≤10% Time Delay: ≤80 μs Repeat Accuracy: 0.1 mm Sensor Face Type: PBTP Housing Material: Nickel Plated Brass Cable Length: 300 m Sensor Height: 35 mm Operating Temperature Range: -25 to +70 °C Mounting Type: Embeddable IP Rating: IP67 Weight: 95.5 g Voltage Drop: ≤2 V @ 200 mA
