LFG-1020-050, Fiber Optic Sensor 50 mm 25 mm Bending Radius
Product Attributes
Shape: Rectangular Measuring Distance: 0 to 60 mm Optimum Operating Distance: 40 mm Counting Rate: <600000 Copies/h Object Speed: <5 m/s Object Cycle Distance: >1 mm Sensitivity: Single Sheet/Edge Thickness 0.2 mm Output Pulse Length: 5/10/15/20 ms Selectable Synchronous Input (Yes/No): No Measuring Point: Visible Red Laser Line 2 mm Light Source: Pulsed Red Laser Diode Wave Length: 670 nm Edge Indicator: Yellow LED Power on Indication: Green LED Sensitivity Adjustment Type: High/Low Switchable Supply Voltage: 10 to 30 V dc Output Circuit: Push-Pull Current Consumption: 180 mA Housing Material: PA 6 Front Optics: Glass Width: 30 mm IP Rating: IP 54 Operating Temperature: 0 to +50 °C [$]Standards Met: CE Certified cULus Listed
