LFG-1020-050, Fiber Optic Sensor 50 mm 25 mm Bending Radius
Product Attributes
Sensing Range: 40 mm Polarity: Analog Connection Type: M12 4-Pin Thread Size: M30 x 1.5 Connector Size: 30 mm Supply Voltage: 15 to 30 V dc No-Load Supply Current: ≤12 mA Voltage Output: ≤15 mA Current Output Rating: 0.4 kΩ (Ub=10V) Maximum Tightening Torque: 70 Nm Bandwidth: 100 Hz Temperature Drift: ≤5% (0 to +70°C) Time Delay: 20 μs Recovery Time: 10 μs Repeat Accuracy: ± 0.35 mm Sensor Face Type: PBTP Housing Material: Chrome Plated Brass Cable Length: ≤300 m Sensor Height: 73.5 mm Operating Temperature Range: -25 to +70 °C Mounting Type: Non Embeddable IP Rating: IP67 Weight: 155 g Static Resolution: ≤1.42 @ 0.67·Sd µm
