LFG-1020-050, Fiber Optic Sensor 50 mm 25 mm Bending Radius
Product Attributes
Sensing Range: 1.5 mm Polarity: NPN Connection Type: 2 m 3 Wire Connector Size: 4 mm Supply Voltage: 10 to 30 V dc Current Rating: ≤200 mA No-Load Supply Current: ≤10 mA Leakage Current: ≤0.1 mA Maximum Switching Frequency: ≤3000 Hz Oscillator Frequency: 950 kHz Temperature Drift: ≤10% Time Delay: 10 μs Repeat Accuracy: 0.03 mm Sensor Face Type: POM Housing Material: Stainless Steel V2A Cable Length: 100 m Sensor Height: 25 mm Operating Temperature Range: -25 to +70 °C Mounting Type: Embeddable IP Rating: IP67 Weight: 39 g Voltage Drop: ≤2 V @ 200 mA
