OPDM 16P5102 Retro-Reflective Laser Sensor

Product Attributes

• Shape:Rectangular
• Actual Range:11 m
• Nominal Range:12 m
• Light Source:Pulsed Red Laser Diode
• Polarization Filter (Yes/No):Yes
• Alignment/Soiled Lens Indicator:Flashing Light Indicator
• Light Indicator:Yellow LED
• Wave Length:650 nm
• Output Circuit:PNP
• Output Current:<200 mA
• Output Function:Light/Dark Operate
• Response Time/Release Time:<0.1 ms
• Supply Voltage:10 to 30 V dc
• Reverse Polarity Protection (Yes/No):Yes
• Front Optics:Glass
• Connection Type:2 m 4-Pin Cable
• Housing Material:Die-Cast Zinc
• Dimension:50 x 15.4 x 50 mm
• IP Rating:IP 67
• Operating Temperature:-10 to +50 °C
• Standards Met:CE Certified
  cULus Listed
