Switching Power Supply Unit

Product Attributes

• Brand:Sprecher + Schuh
• Product Type:Switching Power Supply Unit
• Phase:2-Phase
• Input Voltage:230
  400 to 500 V ac
• Output Voltage Rating:24 V dc
• Efficiency Level:89 %
• Over-Load Level:50 %
• Power Continuity Rating:96 to 120 W
• Short Circuit Protection Mode:Hiccup
  Continuous Mode
  Restart After Main
• Inrush Current Rating:? 17 A @ ?5 msec
• Frequency Rating:47 to 63 Hz
• Internal Fuse Current:T 4 A
• External Fuse Current:10 A
• Load Capacity:?50000 ?F
• Maximum Delay Time:1 s
• Output Current Rating:5 A
• Short Circuit Current Rating:12 A
• Hold-Up Time:20 ms
• Ripple:? 80 mVpp
• Maximum Dissipation Load:12 W
• Connection Type:Parallel
• Operating Temperature Range:-25 to +70 °C
• Storage Temperature Range:-40 to +85 °C
• Humidity Range:95 %
• Isolation Voltage:3000 V ac (In/Out)
  1605 V ac (In/PE)
  500 V ac (Out/PE)
