LFG-1020-050, Fiber Optic Sensor 50 mm 25 mm Bending Radius
Product Attributes
Shape: Rectangular Scanning Range: 100 to 1000 mm Output Signal: 0 to 10 V/10 to 0 V Resolution: <0.3 mm Light Indicator: Yellow LED/Red LED Adjustment Type: Teach-In Response Time: <80 ms Repeat Accuracy: 0.5 mm Supply Voltage: 15 to 30 V dc Output Current: <20 mA Connection Type: M8 Connector Output Circuit: Voltage Output Switching Frequency: 240 kHz Short Circuit Protection (Yes/No): Yes Reverse Polarity Protection (Yes/No): Yes [$]Housing Material: Polyester Dimension: 42 x 20 x 15 mm [$]IP Rating: IP 67 [$]Operating Temperature: -10 to +60 °C [$]Standards Met: CE Certified
